DISCLAIMER: For order basis with 30-45 days lead time.
Only available in APAC
4MP (2688*1520)
True WDR120dB
2.8mmLens
H.265
Built-In Mic
IR, IP67
Specification:
Image Sensor 1 / 2.8" Progressive Scan CMOS
Min Illumination Color: 0.003Lux (F1.6, AGC ON) | 0Lux with IR
Shutter Time Auto/Manual, 1 ~ 1/100000s
Lens 2.8mm@F1.6
True WDR 120 dB
Angle of View H: 101.1°, V: 55.3°, O: 111.1°
Angle Adjustment Pan: 0° ~ 360° | Tilt: 0° ~ 90° | Rotate: 0° ~ 360°
3-Axis Adjustment Yes
Day & Night IR-Cut Filter with Auto Switch (ICR)
IR Range Up to 50m (98ft) IR range
Video Compression H.265, H.264, MJPEG
Video Bit Rate 128 Kbps~16 Mbps
Two Stream Yes
Analytics Motion Detection
Max. Image Resolution 2688*1520
Frame Rate 25fps (2688*1520)
ROI Codec Up to 8 areas
Image Setting White Balance, Digital Noise Reduction, Smart IR, Flip, HLC, BLC
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP,
HTTP, HTTPS, SMTP, SSL/TLS, 802.1x, SNMP
Communication Interface 10M/100M Base-TX Ethernet
Local Storage Yes 256G micro SD card
Audio G.711
Safety CE, IEC62368-1
EMC FCC Part 15, EN 55032:2015+A11:2020, EN 55035: 2017+A11:2020
Operating Conditions Temperature: -30°C~60°C(-22°F~140°F),
Humidity:≤95%RH(Non-Condensing)
Power Consumption Max 6.0 W
Power Supply DC 12V±25%, PoE (IEEE 802.3af)
Weather Proof Rating IP67
Dimensions 191×73×71mm (7.5”×2.9”×2.8”)
Net Weight 0.45kg (0.99lb)
Software No license required for use with Video Insight Software
