Technical Specifications |
|
| |
|
|
| |
Camera |
|
| |
Image Sensor |
1/2.7" 5-megapixel progressive scan CMOS |
| |
Effective Pixels |
2560 (H) x 1920 (V) |
| |
Minimum Illumination |
Color: 0.005 lux (F1.2, AGC ON, 1/30s shutter speed) |
| |
|
B/W: 0.0005 lux (F1.2, AGC ON, 1/30s shutter speed) |
| |
Day/Night Mode |
Automatic ICR, color, or B/W |
| |
Shutter Speed |
1/68250s to 1/3s |
| |
Gain Control |
Auto/Manual |
| |
W D R |
120 dB |
| |
Backlight Compensation (BLC) |
Supported |
| |
White Balance |
Auto/Manual |
| |
H L C |
Supported |
| |
Image Defogging |
Auto/Manual/Off |
| |
Digital Noise Reduction (DNR) |
2D/3D noise reduction |
| |
Electronic Image Stabilization |
Supported |
| |
|
|
| |
Lens and Illuminator |
|
| |
Focal Length |
2.8mm/3.6mm/6mm |
| |
Maximum Aperture |
F1.6 |
| |
Iris Type |
Fixed iris |
| |
Maximum Radiation Distance |
30 m |
| |
|
|
| |
Function |
|
| |
Video Encoding Format |
H.265/H.264/MJPEG |
| |
Maximum Resolution |
2560 x 1920 |
| |
Frame Rate |
Configurable (25 fps or 30 fps) |
| |
Video Bit Rate |
32 kbit/s to 16 Mbit/s |
| |
Multi-Channel Encoding |
Triple streams |
| |
Intelligent Encoding |
Extra265/264 |
| |
Camera Connection Protocol |
ONVIF Profile S/G/T, GB/T 28181 (2011, 2016), Huawei SDK, and Huawei Rest API |
| |
Network Protocol |
TCP, UDP, IPv4, IPv6, DHCP, DHCPv6, DNS, ICMP, ICMPv6, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP, (V1/V2/V3), 802.1X, QoS, and DDNS |
| |
Security Mode |
User name and password authentication, 802.1X access, authentication, and HTTPS digital certificate |
| |
Media Security |
Fragile digital watermark AES256-based stream encryption |
