Overview
Read details more clearly and see high-contrast color with new high-definition HP printheads. HP Pixel Control enables smooth gradients, and the integrated vertical trimmer streamlines finishing.1 Handle complex files and secure your printers/data.
Dynamic security enabled printer. Only intended to be used with cartridges using an HP original chip. Cartridges using a non-HP chip may not work, and those that work today may not work in the future.
PRECISE—Clearly distinguish subtle details
Read details more clearly and see high-contrast color with new high-definition HP printheads.
No need for light inks with HP's dual drop technology.
Get smooth gradients, even for challenging color combinations, with HP Pixel Control.
SECURE—Protect your work and your information
Protect printers/data from unauthorized access with HP Secure Boot, whitelisting, and encrypted hard disk.
Protect documents, preserve confidentiality with authentication solutions like PIN printing, card readers.5
Secure your printers with HP JetAdvantage Security Manager; manage your fleet remotely with HP Web Jetadmin.
FAST—Work without delays
Handle even the most complex files with powerful processing architecture and the Adobe PDF Print Engine.3
Cut maps to different sizes in fewer steps with the first printer including an integrated vertical trimmer.1
Print up to 20% faster4 with 2400 nozzle-per-inch, high-definition HP printheads.
Specifications
Functions : Print
Model size : 1118 mm
Print speed : Fast: 80.5 m²/hr on plain media; Normal: 18.8 m²/hron coated media; Best: 9.7 m²/hr on glossy media[1]
Print technology : HP Thermal Inkjet
Printer drivers included : Raster and PostScript drivers for Windows and macOS; PDF driver for Windows 8 and above
Print quality color (best) : Up to 2400 x 1200 optimized dpi
Print languages : Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL
Number of print cartridges : 6 (cyan, magenta, yellow, matte black, photo black, chromatic red)
Ink types : Pigment-based
Line accuracy : ±0.1%[5]
Color Stability : < 1 dE2000 in less than 5 minutes[7]
Print repeatability : Average < 0.5 dE2000, 95% of colors < 1.4 dE2000[7]
Maximum optical density (black) : 4 L* min/2.5 D[7]
Connectivity, standard : Ethernet, Fast Ethernet, Gigabit Ethernet, 10/100/1000Base-T Ethernet (802.3, 802.3u, 802.3ab); Hi-Speed USB 2.0 certified interface for direct printing from USB flash drive
Network ready : Standard
Memory : 128 GB (virtual)[8]
Internal Storage : 500 GB self-encrypting
Finished output handling : Roll feed, top sheet feed, media output bin, automatic horizontal cutter
Media sizes standard (metric rolls) : 279 to 1118-mm
Media sizes, custom : 210 x 279 to 1118 x 1676 mm Media types : Photographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit
Media weight, recommended : 80 to 500 g/m²
Roll external diameter : 135 mm
Media thickness : Up to 31.5 mil
Power : Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max
Power consumption : < 100 W (printing); < 32 W (ready); < 0.3 W (< 6.5 W with embedded Digital Front End) (sleep); 0.1 W (off)
ENERGY STAR® certified : Yes
Operating temperature range : 5 to 40ºC
Minimum dimensions (W x D x H) : 1802 x 695 x 998 mm
Weight : 86 kg
Package dimensions (W x D x H) : 1950 x 766 x 718 mm
Package weight : 123 kg
What's in the box : HP DesignJet Z6 PostScript Printer, printheads, introductory ink cartridges, printer stand and media bin, spindle, 3-in core adapter, quick reference guide, setup poster, power cord
Software included : Printer drivers / HP Click / HP Web Jetadmin /HP JetAdvantage Security Manager /HP DesignJet Utility including HP Color Center / HP Partner Link Pay-per-use /HP MPS
