| Model Number |
PSA1000-SOHO |
| Capacity (VA/W) |
1000VA/600W |
| Input |
|
| Voltage range |
162 – 290VAC, single-phase |
| Frequency range |
50Hz/60Hz automatic identification |
| Output |
|
| Voltage tolerance (Batt. Mode) |
Simulated sine wave at nominal voltage ±10% |
| Frequency range (Batt. Mode) |
50Hz/60Hz automatic identification |
| Transfer time |
Typical 2–6 ms, 10ms max. |
| Battery |
|
| Battery type & Number |
12V/9AH × 1 |
| Typical recharge time |
6-8 hours recover to 90% capacity (About 1A charging current at Normal Mode) |
| Configuration: Battery |
1×2.7kg, 9Ah |
| Configuration: Sockets |
6×Universal |
| Configuration: USB Charger |
*0 |
| Runtime: Time (in minutes) |
|
| Load: 25% |
18m |
| Load: 50% |
4m |
| System Features |
|
| Indicators AC Mode: |
Solid green led lighting; Battery Mode: Solid yellow led flash; Fault Solid: Red led lighting |
| Protection |
Discharge, Overload and overcharge protection |
| Alarm |
1.) Battery Mode: Sounding every 10 seconds; 2.) Low battery: Sounding every 1 second; 3.) Overload: Sounding every 0.5 second; 4.) Fault: Continuously sounding |
| Operating temperature |
0 ~ 40°C |
| Humidity range |
0 ~ 95% (non-condensing) |
| Noise level |
Less than 40dB (1 meter from surface) |
| Fuse Protection |
YES |
| USB Charging slot |
NO |
| Physical |
|
| Dimension D × W × H (mm) |
87 × 346 × 208 |
| Gross weight (kg) |
6.6 kg |
| Net weight (kg) |
6.0 kg |
