Blink500 TX
Transmission Type: 2.4GHz Digital Frequency
Modulation: GFSK
Operating Range: Up to 164′ (50m)
RF Output Power: 10mW
Polar Pattern: Omnidirectional
Frequency Response: 50Hz-18KHz
Maximum SPL: Built-in Microphone:120dB SPL
Lavalier Microphone: 110dB SPL
Sensitivity: Built-in Microphone: -42dB
Lavalier Microphone: -30dB
SNR: ＞78dB
Power Requirements: Built-in Li-ion Battery or USB-C DC 5V
Built-in Battery Life: Approx. 6 hours
Antenna: PIFA Antenna
Audio Inputs: 3.5mm TRS Lavalier Microphone Input
or Built-in Microphone
Weight: Approx. 34g (1.2oz)
Dimensions: 63×43×16.5mm
Operating Temperature: 0°C to 50°C
Storage Temperature: –20°C to +55°C
Blink500 RXUC
Transmission Type: 2.4GHz Digital Frequency
Modulation: GFSK
Operating Range: Up to 164′ (50m)
Audio Output Connector: USB-C Connector
Power Requirement: Supplied by USB-C Device
Antenna: PIFA Antenna
Weight: Approx. 10.5g (0.37oz)
Dimensions: 76×16.5×11mm
Operating Temperature: 0°C to 50°C
Storage Temperature: –20°C to +55°C
