Min. illumination/Low Light Mode (Colour) Color : 0.1 Lux at F1.4 ; B/W : 0.02 Lux at F1.4 ; 0 Lux with IR LED ON
Operating temperature -40°C – +50°C (-40°F – 122°F)
Storage temperature -25°C – +60°C (-13°F – 140°F)
Operating humidity 0% – 90% RH
Power Supply DC12V ±10% / PoE (IEEE 802.3af compliant)
Power Consumption DC12V, 8.4W / PoE, 10W
Focal Length 2.8 – 12mm
Iris F1.4
Angle of View 102° (W) – 34° (T) (H) 54° (W) – 20° (T) (V) 122° (W) – 39° (T) (D)
Peak wavelength 850nm
Max IR distance 30M
Pick Up Element 1/2.7" CMOS image sensor
Effective pixels 1920 (H) × 1080 (V) = 2,073,600 (Pixels)
CE Yes, EMI CLASS B
FCC Yes, EMI CLASS B
IP Rating IP67
Vandal Resistant Rating / IK Rating IK10
CPU Intel® Core™ i3 or higher grade
OS Windows 7 or above
RAM 4GB or above, Dedicated Graphics Card
Web browser Microsoft® Internet Explorer® 9 or above
Dimensions 68(W) × 69(H) × 214(D) mm approx
Weight 490g approx
Window / Glass Thickness Ø58 Heat Resistant Glass
Video Compression H.264 main and high profile, Motion JPEG
Video streaming RTP/HTTP, RTP/TCP, RTP/UDP, Multicast; 3 configurable streams in H.264 and Motion JPEG, configurable frame rate, bandwidth Codec and GOP
Video bitrate 128Kbps – 12Mbps; Frame rate and bit rate controllable on-the-fly; VBR / CBR / GOP supported; Fixed bitrate; Smart H.264
Encryption Base64 HTTP encryption
Authentication Digest HTTP authentication, RTSP authentication, DDNS via HTTPS
Access Multiple user access levels with password protection
User accounts 10 simultaneous users
Multi IP address Yes
Resolution 2MP(1920 × 1080), 1.3MP(1280 × 960), 1MP(1280 × 720), D1(720 × 480, 720 × 576), VGA(640 × 480), CIF(352 × 240)
Maximum Frame Rate H.264 / MJPEG : up to 30 fps @ 1920 × 1080
Scanning System Progressive Scan
Infrared Cut Filter Auto / Day (Color) / Night (Mono) / Schedule
White Balance Auto / Tungsten / Indoor / Fluorescents1 / Fluorescents2 / Outdoor1 / Outdoor2
Electrical Shutter 1/30(1/25)s – 1/30000s
Sense Up Off / 1 Frame / 2 Frames
Sense Up+ Yes
Auto Gain Control 42 dB Variable Gain
3D Noise Reduction Off / 1 – 32 Selectable
2D WDR Off / Auto / x2 / x3 / x4 (by normal mode)
High Dynamic Range(HDR) Up to 100dB (in HDR mode, 2 shutter line interleave)
Privacy Masking Off / On (4 zones)
Image Effects Brightness, Contrast, Hue, Saturation, Sharpness, Mirror, Flip
Mobile Application Integrated to LILIN mobile app (LILIN Viewer), iPhone, iPad, Android support
Video Management ONVIF Profile S, LILIN Navigator Enterprise 2.0, Third party VMS through LILIN HTTP API
SD Card (recording) Support Micro SD/SDHC/SDXC (up to128GB) card for circular recording (card is not included)
Firmware Firmware update via HTTP and IP Scan; Firmware available at website
IVS Basic 1.0 Motion Detection, Tampering Detection, Advanced Motion Detection, Traffic Light Detection, Tripwire Detection, Object Counting
Alarm event triggers Motion / Tamper / Network lost detection
Alarm event actions FTP / SMTP / HTTP post / SD card / SAMBA / SNMP Trap / Push Service notification
Languages English, Traditional Chinese, Simplified Chinese, Spanish, Italian, Turkish, Russian, Korean, French, Arabic, Hungarian, Japanese
Protocols IPv4, IPv6, TCP, UDP, HTTP, HTTPS, SMTP, MQTT, QoS, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SDDP, Bonjour, SSL/TLS
Video Display LILIN Universal ActiveX, LILIN Java Applet & HTML5 |
