Overview
Immediately update all your partners on project review results with the most compact large-format MFP.1 Intuitive, convenient print/scan/copy and HP DesignJet print quality help you communicate effectively and move the project forward.
Dynamic security enabled printer. Only intended to be used with cartridges using an HP original chip. Cartridges using a non-HP chip may not work, and those that work today may not work in the future.
CONVENIENT—Fast, agile, intuitive print/scan/copy
Print documents fast—up to 26 seconds for A1/D-size prints.2
Enjoy easy installation in the office, construction job site with the most compact large-format MFP.1
Easily print project sets and PDF documents with HP Click printing software.
COMMUNICATION—Immediately share meeting results
Use built-in scanner to copy and distribute sketches and hand-annotated drawings to peers/partners right away.
Easily link your computer, smartphone, or tablet to the printer with Wi-Fi Direct.
Share drawings immediately—scan/email from front panel, use HP Smart app5 to email contacts, post to cloud.
TRUSTED—HP DesignJet quality and reliability
Get HP DesignJet quality also in small-format sizes—print half-size documents with 50-sheet A4/A3 input tray.
Achieve precise lines up to 0.1% line accuracy3, up to 2400 dpi, and high contrast—HP Bright Office Inks.
Smart scanning technology protects originals from damage when scanning and obtains precise colors.
Specifications
Functions : Print, copy, scan
Model size : 610 mm
Print speed line drawing (economode, A1 plain paper) : 81 A1 prints per hour
Print technology : HP Thermal Inkjet
Printer drivers included : Raster driver for Windows and macOS; HP-GL/2, HP-RTL drivers for Windows
Print quality color (best) : Up to 2400 x 1200 optimized dpi
Print languages : TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL, URF
Number of print cartridges : 4 (cyan, magenta, yellow, matte black)
Ink types : Dye-based (C, M, Y); pigment-based (mK)
Line accuracy : ±0.1%
Maximum optical density (black) : 8 L* min/2.10 D
HP ePrint capability : Yes
Connectivity, standard : Gigabit Ethernet (1000Base-T); Wi-Fi 802.11b/g/n; Wi-Fi Direct; USB Type-A host port
Connectivity, optional : HP USB 3.0 to Gigabit LAN Adapter
Network ready : Standard
Memory : 1 GB
Maximum Memory : 1 GB
Internal Storage : None
Finished output handling : Sheet feed; roll feed; input tray; media bin; automatic cutter
Media sizes standard (metric rolls) : 210 to 610-mm wide sheets; 279 to 610-mm rolls
Media sizes, custom : Input tray: 210 x 279 to 330 x 482 mm; manual feed: 330 x 482 to 610 x 1897 mm; roll: 279 to 610 mm
Media types : Bond and coated paper (bond, coated, heavyweight coated, recycled, plain, bright white), technical paper (natural tracing, vellum), film (clear, matte), photographic paper (satin, gloss, semigloss, premium, polypropylene), self-adhesive (adhesive, polypropylene)
Media weight, recommended : 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray)
Roll external diameter : 100 mm
Media thickness : Up to 11.8 mil
Scanner type : Sheetfed, CIS (Contact Image Sensor)
Scan resolution, optical : Up to 600 dpi
Enhanced scanning resolution : 600 dpi
Bit depth : 24-bit/8-bit
Scan size, maximum : 610 mm x 2.77 m
Linear scan speed : Up to 3.81 cm/sec (color, 200 dpi); up to 11.43 cm/sec (grayscale, 200 dpi)
Copy resolution (color text and graphics) : Up to 600 x 600 dpi
Copy reduce / enlarge settings : 50 to 400%
Copies, maximum : Up to 99 copies
Copier settings : Content type; Lighter/Darker; Background noise removal; Background color removal; Blue print invert; Translucent media; Color; Scan full width (24-in); Auto De-skew; Resize; Copy Margins; Quality
Power : Input voltage: 100-240 V, 50/60 Hz, 1.2 A max
Power consumption : 35 watts (printing), 3.5 watts (sleep), 0.2 watts (standby)
ENERGY STAR® certified : Yes
Operating temperature range : 5 to 40ºC
Minimum dimensions (W x D x H) : 1098 x 629 x 1155 mm
Weight : 51 kg
Package dimensions (W x D x H) : 1310 x 570 x 645 mm
Package weight : 70 kg
What's in the box : HP DesignJet T830 24-in MFP/ printhead : ink cartridges / printer stand : spindle
quick reference guide / setup poster /power cord / refeed preventers / Software included /HP Click
HP DesignJet Utility for Mac and Windows
