Placing and Accessing the Scanner
Insufficient space is not an issue due to the compact design of the SP-1425. This scanner is designed to be used in all kinds of situations, including in places where space is limited.
-Scanning both sides of a document in one go
The ADF, which has a duplex scanning mode function, and the flatbed have been combined into a single compact scanner.
-Can be placed anywhere
The scanner can be used for any purpose in accordance with your business needs, such as scanning documents for clerical work purposes at an office and for identification/application purposes at a reception desk.
An all-round model providing excellent operability. The scanner with the flatbed and the ADF, which has a stable paper feed function, supports your demands in order to raise business efficiency by meeting your needs for scanning various documents.
-Fast scanning speed at a rate of 25 ppm / 50 ipm
Fast scanning capability in duplex scanning mode with the ADF, 25 ppm/50 ipm (A4 portrait, color 200 dpi/300 dpi) has been enabled.
-Efficiency made possible by combining flatbed and ADF
Equipped with an ADF and flatbed, SP-1425 can scan various documents, from batches of paper to plastic cards* and passports.
* Flatbed Only
-A wide variety of scanning solutions available
Combining multiple software to work together with your business system allows you to use these solutions with ease thus improving and making your business more efficient.
Supported operating systems: Windows® 10 (32-bit/64-bit), Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2019 (64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit),Windows Server® 2008 (32-bit/64-bit), Linux (Ubuntu)(2)
Scanner Type: Automatic Document Feeder (ADF) and Flatbed
Scanning modes: Simplex / Duplex, Color / Grayscale / Monochrome
Image Sensor Type: Single line CMOS-CIS x 2 (Front / Flatbed x 1, Back x 1)
Light Source: R, G, B LED x 2 (Front / Flatbed x 1, Back x 1)
Multifeed detection: Ultrasonic Multi-feed Detection Sensor x 1
Maximum: 216 x 356 mm (8.5 x 14 in.)
Minimum: 114 x 140 mm (4.5 x 5.5 in.)
Long page scanning: 216 x 3,048 mm (8.5 x 120 in.)
Maximum: 216 x 297 mm (8.5 x 11.7 in.)
Minimum: 25.4 x 25.4 mm (1 x 1 in.)
Paper weight (Thickness)
Paper: 52 to 127 g/m2 (14 to 34 lb)
Plastic Card: Not Support
Carrier sheet: Not Support
Scanning speed (A4, Portrait)
Simplex: 25 ppm (200 dpi / 300 dpi)
Duplex: 50 ipm (200 dpi / 300 dpi)
Color/Grayscale/Monochrome: 4 Seconds (200 dpi / 300 dpi)
Paper chute capacity (A4 Portrait): 50 sheets (A4: 80 g/m2 or 21 lb)
Expected Daily Volume: 4,000 sheets
Optical Resolution: 600 dpi
Color (24-bit),Grayscale (8-bit),Monochrome (1-bit):
50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (10)
Internal video processing: 65,536 levels (16-bit)
Interface: USB2.0 / USB 1.1
Connector shape: B type
Image processing function: Image emphasis, Error diffusion, Dither, Dynamic threshold (iDTC), Static threshold, Advanced DTC, SDTC, De-Screen, Dropout color(Red, Green, Blue, White, None, Saturation, Custom), Automatic color detection, Multi image output, Blank page detection, sRGB Output, Split image, Vertical streaks reduction, Edge Filler, Automatic page size detection
Power requirement: AC 100 V to 240 V ± 10%
Power consumption: Operating: 16 W or less
Sleep mode: 2.9 W or less
Auto standby (OFF) mode: 0.5 W or less
Temperature: 5 to 35 °C (41 to 95 °F)
Relative humidity: 20 to 80% (Non-condensing)
Dimensions: Width x Depth x Height (12) 454 mm x 331 mm x 129 mm (17.9 in. x 13 in. x 5.1 in.)
Weight 4.3 kg (9.5 lb) or less
Included software / drivers: PaperStream IP for SP Series driver (TWAIN/TWAIN x64/ISIS), WIA Driver(13), PaperStream Capture Lite, Software Operation Panel, Error Recovery Guide, Presto!™ PageManager™(14), ABBYY™ FineReader™ Sprit(14), Scanner Central Admin
Environmental compliance: ENERGY STAR® and RoHS
Included items: Pad Unit, AC adapter, AC cable, USB cable, Setup DVD-ROM, Included items Quick Installation Sheet
