Comfortable scanning
The SP-1130 enables stress-free operation with 30 ppm scanning that does not drop speeds even when scanning in 300 dpi resolution and ADF that holds up to 50 sheets at a time. Accurate page feeding with brake roller separation and multifeed detection with the ultra-sonic sensors allow users to scan without worrying about any unexpected interruptions.
Document handling for various scanning needs
The scanner handles a wide range of paper from thin to thick, as well as plastic cards to suit all scanning needs. When using the scanner at reception desks, application forms and plastic ID cards can be scanned at the same time so that receptionists can offer better customer service with less wait time.
Functional Specification
Supported operating systems: Windows® 10 (32-bit/64-bit), Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2019 (64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit),Windows Server® 2008 (32-bit/64-bit), Linux Ubuntu(1)
Scanner Type: ADF (Automatic Document Feeder)
Scanning modes: Simplex / Duplex, Color / Grayscale / Monochrome
Image Sensor Type: Single line CMOS-CIS x 2 (Front x 1, Back x 1)
Light Source: R, G, B LED x 2 (Front x 1, Back x 1)
Document size: Maximum: A4 Portrait (210 x 297 mm) or Legal (8.5 x 14 in.) or 8.5 x 34 in. (215.9 x 863.6 mm) (long page scanning: 3,048 mm (120 in.))
Minimum: A8 Portrait / Landscape (52 x 74 mm)
Supported operating systems: Windows® 10 (32-bit/64-bit), Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2019 (64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit),Windows Server® 2008 (32-bit/64-bit), Linux Ubuntu(1)
Scanner Type: ADF (Automatic Document Feeder)
Scanning modes: Simplex / Duplex, Color / Grayscale / Monochrome
Image Sensor Type: Single line CMOS-CIS x 2 (Front x 1, Back x 1)
Light Source: R, G, B LED x 2 (Front x 1, Back x 1)
Document size Maximum: A4 Portrait (210 x 297 mm) or Legal (8.5 x 14 in.) or 8.5 x 34 in. (215.9 x 863.6 mm) (long page scanning: 3,048 mm (120 in.))
Minimum: A8 Portrait / Landscape (52 x 74 mm)
Paper weight (Thickness)
Paper: 50 to 209 g/m2 (0.06 to 0.26 mm)* A8 size: 127 to 209 g/m2 (0.15 to 0.26 mm)
Plastic Card: ISO7810 ID-1 type compliant (0.76 mm or less, embossed plastic cards with total thickness of 1.24 mm or less)
Scanning speed (A4, Portrait)
Color|Grayscale|Monochrome: Simplex: 30 ppm (200 dpi / 300 dpi) Duplex: 50 ipm (200 dpi / 300 dpi)
Paper chute capacity (A4 Landscape): 50 sheets (A4: 80 g/m2 or 20 lb)
Expected daily volume: 4,000 sheets/day
Background colors: White (Hardware, scanned background is gray)
Optical Resolution: 600 dpi
Output Resolution:
Color (24-bit)|Grayscale (8 bit)|Monochrome (1 bit): 50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)
Output format: Color: 24-bit, Grayscale: 8-bit, Monochrome:1-bit
Internal video processing: 65,536 levels (16-bit)
Interface: USB2.0
Connector shape: B type
Image processing function: Auto color detection, Automatic page size detection, De-Skew, Multi-image, Blank page skip, Error diffusion, Dropout color (R, G, B, Saturation), Image emphasis, Advanced DTC, sRGB, Halftone, Smoothing, Split image, Vertical streaks reduction, Digital endorser, Edge correction, Dynamic threshold(iDTC)
Power requirement: AC 100 V to 240 V ± 10%
Power consumption
Operating: 18 W or less
Sleep mode: 1.6 W or less
Auto standby (OFF) mode: 0.4 W or less
Operating environment
Temperature: 5 to 35 °C (41 to 95 °F)
Relative humidity: 20 to 80% (Non-condensing)
Dimensions: Width x Depth x Height : 298 mm x 135 mm x 133 mm (11.7 in. x 5.3 in. x 5.2 in.)
Weight 2.5 kg
