Key Features
4/8/16-channel input
Plug & Play with 4/8 independent PoE network interfaces
Third-party IP cameras supported with ONVIF conformance
Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840x2160) resolution
Up to 8 Megapixels resolution recording
Support H.265/H.264 video formats
Accurate retrieval, instant playback
1 SATA HDD up to 8 TB
Support for P2P, UPnP, NTP, DHCP, PPPoE
Support for mobile client access
Specifications
Model
Video/Audio Input
IP Video Input : 4-ch
Two-way Audio Input : 1-ch, RCA
Network
Incoming Bandwidth : 40Mbps
Outgoing Bandwidth : 64Mbps
Remote Users : 128
Video/Audio Output
HDMI/VGA Output : HDMI: 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720
/60Hz, 1024x768 /60Hz
VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
Recording Resolution : 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output : 1-ch, RCA
Synchronous Playback : 4-ch
Decoding
Compression : H.265/H.264
Live view/ Playback : 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability : 1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30, 16 x D1
Hard Disk
SATA : 1 SATA interface
Capacity : up to 8TB for each disk
External Interface
Network Interface : 1 RJ-45 10M/100M self-adaptive Ethernet Interface
USB Interface : Rear panel:2 x USB2.0
PoE
Interface : 4 independent 100 Mbps PoE network interfaces
Max Power : Max 30W for single port / Max 54W in total ( 13.5W for each )
Supported Standard : IEEE 802.3at, IEEE 802.3af
General
Power Supply : 48V DC
Consumption ( without HDD ) : ≤ 8 W
Working Temperature : -10°C + 55°C ( +14°F +131°F )
Working Humidity : 10% 90%
Dimensions : 42 × 205 × 205mm ( 1.7" × 8.1" 8.1" )
Weight ( without HDD ) : 0.59kg ( 1.3 lb )
